HYDRAULIC FRONT BLADE

The Power Dozers are designed and built to match the performance of the MT tractors. They are operated hydraulically by single or twin double acting rams. The points of attachment of the dozer to the tractor are reduced to an absolute minimum and the mounting brackets, once fitted, can be left in position enabling the sub-frame and blade to be quickly removed and attached. The blade is fitted with a reversible and replaceable cutting edge of high cardoon steel.

HYDRAULIC FRONT BLADE

Specifications
Power Dozer to fit MF 240, 350 Plus, 260, 360, 375, 385 tractors
Blade Model MT-08/1=6′ * 22″ -(Single ram)

Model MT-08/2=6.5′ * 30″ (Twin ram)
Cutting Edge 152 mm (6″) * 12.7 mm (1/2:) section high carbon/alloy steel reversible and replaceable
Hydraulic Ram Heavy duty, double acting
Control Value Open centre double acting spool value
Blade Movement Maximum lift 533 mm (21″) .Maximum depth below ground 102 mm (4″)
