Introducing TRICYCLE 6 SEATERS

The 6 Seaters is a modified version of the highly successful Superior Model. With a capacity of carrying 6 passengers in addition to the driver with safety features this model is ideal for fixed routes or organizations looking to run shuttle services between two points.

TRICYCLE 6 SEATERS

Technical Specifications
Component Specifications
Engine Type 4 Stroke
Cooling Type Water Cooled
Displacement 200cc
Max. Power 11 KW
Max. Torque 16 KW
Ignition Type COI
Transmission Type Rear Engine Axle 5+1
Clutch Type Wet Multi Disc (7 Plates)
Electrical System 12V DC
Head Light 35W 12V
Horn 82-85 db
Chassis Type Pipe Frame Structure
Maximum Payload 400 Kg
Component Specifications
Front Suspension Hydraulic Shock Absorber
Rear Suspension Leaf Spring Shock
Front Tyre Size 10.35 Pr
Front  Brake Drum Mechanical
Rear Brake Hydraulic Drum Type
Fuel Tank Capacity 6.5 Liters
Overall Length 2920 mm
Overall Width 1200 mm
Overall Height 1785 mm
Wheel Base 1995 mm
Ground Clearance 145 mm
Gross Weight 430 Kg
Minimum Turning Radius 21’5″
